Overview
Project No.:
# 1246
Project Type :
Utility-Scale Solar Design
Location :
Utah
Project Description
79.59MW DC / 69.99MW AC; Ground Mount; 6624 Strings; 27 Modules per string. It consists of 178,848 Suntech solar modules with 24 Sungrow central inverters. The project was designed for east-west tracking. 34.5kv AC was provided to the utility with underground cable within the project area to tie to the existing overhead line at POI to comply with NEC and local electric company protection and safety switch requirements.
